Overview
Nanobubble Technology
Biomed Agritech’s Nanobubble Technology generates bubbles with an average diameter of less than 200 nanometers. At this size, the bubbles carry a negative surface charge, allowing them to remain stable in water for extended periods without bursting. Their motion follows Brownian movement, which further contributes to their long-term stability. Due to their large surface area and high gas solubility, nanobubbles can carry dissolved oxygen up to saturation levels—making oxygen transfer up to 6 times more effective compared to conventional aeration methods.

Nanobubbles generate high concentrations of reactive oxidants that support oxidative degradation processes. This helps reduce BOD, COD, ammonia, nitrate, and fecal coliform levels—significantly improving key water quality indicators, such as dissolved oxygen. At the same time, organic silt is oxidized and broken down, helping eliminate odors, enhance water clarity and color, and restore overall water quality. Nanobubbles also supply oxygen to various aquatic organisms, supporting respiration and promoting the restoration and rebuilding of healthy aquatic ecosystems. Ultimately, nanobubble technology enhances the water body’s natural self-purification ability and long-term sustainability by effectively reducing total pollutants.
Features
Low Power Consumption
Auto Backwash Nozzle
Self Recovery System
Low Air Pressure System
High Oxygen Transfer efficiency, >95%
Oxygen & Ozone module available as as option
Specifications
Performance | Specification |
---|---|
Gas Type | Air/Oxygen/Ozone |
Oxygen PPM | 10-30 PPM |
Ozone PPM | 0-5 PPM |
Water Type | Fresh Water & Sea Water |
Flow Rate | 20 lpm & 35 lpm |
Coverage Area | 30-50 m³ |
Material Body | SS304 & SS316 |
Motor HP | 1.0 HP & 1.5 HP |
Power Supply | 220V 50Hz |
